Revision List and Downloads:

April 2024

    PC2095 GUI full licences have been issued to RBH, Toowoomba, Ballie, Caboolture and Ipswich sites.

December 2023

    All spare encoders and STC returned to Nexon

December 2023

Ipswich Configuration

• Ipswich Master #50011# RevK PCB running firmware Version 1.80
• Ipswich Slave   #50012# RevK PCB running firmware Version 1.80



• Ipswich STC #40012# RevK PCB running firmware Version 4.06
• Ipswich STC #40013# RevK PCB running firmware Version 4.06
• Ipswich STC #40014# RevK PCB running firmware Version 4.06

September 2022

Caboolture Configuration

• Caboolture Master #50008# RevK PCB running firmware Version 1.70
• Caboolture Slave   #50009# RevK PCB running firmware Version 1.70



• Caboolture STC #40009# RevK PCB running firmware Version 4.06
• Caboolture STC #40010# RevK PCB running firmware Version 4.06
• Caboolture STC #40011# RevK PCB running firmware Version 4.06



March 2022

RBH Block 40 Slave #50003#  Version 1.31 reconfigured to RBH Block 7 #50002# Version 1.60

RBH Block 7 swapped out with upgraded version. Old Block 7 Encoder #50002# upgraded with TCP debug port.

Upgraded Block 7 encoder reconfigured to RBH Block 40 #50003# Version 1.60

    Final RBH Configuration

• RBH Block 7 Master #50002#    RevH PCB + TCP debug port PCB running firmware Version 1.60
• RBH Block 40 Slave   #50003#  RevH PCB + TCP debug port PCB running firmware Version 1.60

• RBH Block 21    STC #40002# RevH PCB running firmware Version 4.06
• RBH Block 7      STC #40003# RevH PCB running firmware Version 4.06
• RBH Block 40    STC #40004# RevH PCB running firmware Version 4.06

November 2021

Final Encoder upgrades from V1.31 to V1.60

• Toowoomba Master #50004# RevK PCB running firmware Version 1.60
• Toowoomba Slave   #50005# RevK PCB running firmware Version 1.60
• Baillie Master         #50006# RevK PCB running firmware Version 1.60
• Baillie Slave           #50007# RevK PCB running firmware Version 1.60

• Toowoomba STC #40005# RevH PCB running firmware Version 4.06
• Toowoomba STC #40006# RevH PCB running firmware Version 4.06
• Baillie STC #40007# RevH PCB running firmware Version 4.06
• Baillie STC #40008# RevH PCB running firmware Version 4.06



8/9/2021

V1.60 September 2021

This is a medium upgrade. (not released)

New Features:

1. added new capcodes functionality to TMP port



   Encoder Set to MASTER Mode	2000025
   Encoder Set to SLAVE Mode	2000026
   Encoder activate SOFT RESET	2000027



2. added to debug port improved version information (!VERS)
   1. added up time in days.
   2. improved display readability



3. added help command !H
4. added OTS activity monitor in version information
5. changed look for power monitor if encoder not transmitting.
6. changed look for OTS if encoder not transmitting
7. changed OTS log to only log if the TCP was present.
   • This allows a Master only system to run without reporting TCP Control warnings.
8. debug logging has a tab between the log integer count and the log string.
9. changed product code from "YRtkeQsAXohTJeFwPnyZiRMjePs" to "MTEL PC2095" and version date and device name.



Bug Fixes:

1. fixed the 32 bit millisecond timer rollover.
   1. This created a problem with the encoder taking in messages on the TMP thread

      and failed to process the transmission thread.





30/6/2021    Release Toowoomba and Baillie Encoders

1. new versions firmware release V1.31 April 2021 Official Release
2. encoder serial nos.
   • Toowoomba Master #50004#    RevK PCB
   • Toowoomba Slave   #50005#    RevK PCB
   • Baillie Master         #50006#    RevK PCB
   • Baillie Slave           #50007#    RevK PCB



19/4/2021    New PCB RevK 03/2021

1. removed processor TCP for debug port.
2. new hardware version adds Lantronix to the debug port.
3. new hardware adds 2nd TCP Control port
4. removed flash memory for TCP config

Bug Fixes:

1. found Lantronix fails to reset to listen mode if TCP is disconnected incorrectly.
2. fixed problem by sending a serial character to the Lantronix input every second
3. the serial character forces the TCP back to listen mode.

29/10/2020

V1.21 June 2020    Official RBH Release

This is the RBH PC2095 release in Block 7.

• RBH Block 7 Master #50002#

1. changed processor TCP for debug port  10.226.80.223  port 10001
2. gateway     10.226.80.129
3. netmask    255.255.255.128

23/10/2020

V1.00 June 2020    Official RBH Release

This is the RBH PC2095 release in Block 7.

• RBH Block 7 Master #50002#
• RBH Block 40 Slave   #50003#

1. added processor TCP for debug port  192.168.0.138  port 10001
2. hardware on PCB PC2095 RevH 06/2020
   • dual power supply detection
   • dual TCP Control
   • on processor TCP port for debug
3. added integer log count for the front of all log messages

27/8/2020

1. improved the TCP Control logic
   • added if both systems RQST at the same time the Master goes first
2. added TMP superset
3. added version information in debug

26/6/2020

V1.00 June 2020    First Official Simulcast Release

This is the RBH spare #50001#

• hardware on PCB PC2095 RevB 10/2019
• dual power supply
• single Lantronix port for TCP control and TMPport

23/5/2020

added processor TCP socket

removed frequency processing

16/4/2020

added transmitter masking

12/2/2020

added TNPP processing

31/12/2019

added Digital Transmitter Control

major upgrades to all modules

25/11/2019

V1.00 November 2019

This is the first hardware/firmware PC2095 release.

Firmware ported from PC2090 (never released)
