PC203 Access Card

Home



Up



Under construction















SiteFG
Picocell_SiteID SeqNo String_Name String_Text Description
RAVENSHOE_NG 1 G_REPEAT equ 03h This is the global number of repeats for each message
RAVENSHOE_NG 2 PC1X5 equ 0h Not in use
RAVENSHOE_NG 3 SRCE_ADD equ 027h Address on the BUS
RAVENSHOE_NG 4 LINKTEST equ 0h not in use
RAVENSHOE_NG 5 ALARM_LEVEL equ 01h 01h means level based alarms. 0h means any toggle creates a message
RAVENSHOE_NG 6 ALARM_MASK equ 01h 0h to 07h . Each bit turns on the alarm. 01h turns on channel 1. 07 turns all three on.
RAVENSHOE_NG 7 ALARM_ACTIVE_LO equ 01h 01h means loss of 12 volts is active or closed circuit is active
RAVENSHOE_NG 8 ALARM_PAGE_RESET equ 0h
RAVENSHOE_NG 9 ALRM_RPT equ 0h
RAVENSHOE_NG 10 PETWDG equ 0h not in use
RAVENSHOE_NG 11 c_RPT_DLY equ 00130h
RAVENSHOE_NG 12 CELLPHONE equ 01h a 01h state means the access card will reset the modem on a regular basis
RAVENSHOE_NG 13 MICROLINK equ 0h not in use
RAVENSHOE_NG 14 ALARM_DISABLE equ 0h
RAVENSHOE_NG 15 SOLAR equ 0h
RAVENSHOE_NG 16 REMOTE_ALARMS equ 0h not in use
RAVENSHOE_NG 17 POWER_MON equ 01h
RAVENSHOE_NG 18 INITSTG equ 01h a 01 enables the modem init string sequence on a reset.
RAVENSHOE_NG 19 LINKDATATEST equ 0h not in use
RAVENSHOE_NG 20 c_SEC_TIME equ 00060h
RAVENSHOE_NG 21 c_EOT_TIME equ 00100h
RAVENSHOE_NG 22 c_PET_TIME equ 01388h
RAVENSHOE_NG 23 c_BUS_TIME equ 01388h
RAVENSHOE_NG 24 c_CYCLE_TEST equ 0300h
RAVENSHOE_NG 25 c_BATT_REPT_limit equ 0552h
RAVENSHOE_NG 26 c_POWER_REPT_l equ 0aa4h
RAVENSHOE_NG 27 c_PET_WTCHDG_l equ 0h not in use
RAVENSHOE_NG 28 c_A_MAJ_LL_limit equ 0h not in use
RAVENSHOE_NG 29 c_LL_MAJ_pollT equ 0h not in use
RAVENSHOE_NG 30 c_ALARM_NODATA_limit equ 0h not in use
RAVENSHOE_NG 31 c_LL_poll_TIME equ 0h not in use
RAVENSHOE_NG 32 c_INIT_MODEM equ 00b00h
RAVENSHOE_NG 33 c_ALARM_FILTER_1 equ 030h this is the delay time before activating the alarm. 030h is about one second
RAVENSHOE_NG 34 c_ALARM_FILTER_2 equ 0300h this is the delay time before activating the alarm
RAVENSHOE_NG 35 c_ALARM_FILTER_3 equ 0300h this is the delay time before activating the alarm
RAVENSHOE_NG 36 c_ALARM_RPT equ 0h
RAVENSHOE_NG 37 c_IO_RELAY_TIMER equ 0h
RAVENSHOE_NG 38 c_POWER_OFF_FILTER equ 03ffh this is the delay time before activating the power off alarm. 03ffh is about 70 seconds
RAVENSHOE_NG 39 c_BATT_OFF_FILTER equ 00ffh this is the delay time before activating the battery bad alarm. 0ffh is about 12 seconds
RAVENSHOE_NG 40 c_PET_MAJ_WTCHDG_l equ 0h
RAVENSHOE_NG 41 c_ISDN_MODEM equ 0deh
RAVENSHOE_NG 42 PETCAPCODE equ 0h a 01h means the PET protocol has capcodes rather than pager numbers.
RAVENSHOE_NG 43 EARLYPOWEROFF equ 0h a 01h sends an initial power off message after about 70 seconds
